The Xencelabs Quick Keys enables artists to incorporate shortcut keys into their regular workflow through an easy-to-use interface. The Quick Keys’s OLED display and physical dial allow you to create up to 40 shortcuts per application and group sets of related functions like sketching, coloring, and editing. Artists who previously found shortcut keys cumbersome to use can now benefit from a powerful efficiency booster.
A: It is about 16 hours. There is a Sleep Timer in the Settings program that you can adjust to help maximize your Quick Keys battery run time.
Q: How long does it take to charge the Quick Keys?
A: It takes about 2.5 hours to fully charge the Quick Keys.
Q: Can I plug the Quick Keys into my cell phone or iPad charging port?
A: No, we suggest that you plug the Quick Keys into your computer’s USB port or a USB hub that is connected to your computer.
Q: I have a Display from another manufacturer, can I still use that Quick Keys?
A: Yes, when you install the Xencelabs Driver, it will ask you if you would like to install only the Quick Keys portion or the entire Driver that also supports our Pen Tablet. You would select Quick Keys only.
Q: Can I connect the Quick Keys to the Bluetooth application on my computer?
A: No, Xencelabs provides a Wireless Dongle to be used to make the Bluetooth connection. Since only Xencelabs products will use this connection, it will eliminate any lag that might be encountered with using the Bluetooth connection that comes with your computer.
Q: Do I need to install a Driver to make the Quick Keys work?
A: Yes, Xencelabs provides a Driver for current or near current macOS, Windows, and Linux operating systems. The Driver must be installed for the Quick Keys to work.
Q: Can I connect the Quick Keys to my stereo, since it has a Bluetooth adapter?
A: No, the Quick Keys is designed to work with a current or near current computer running a full version of macOS, Windows, or Linux, and requires the Xencelabs Driver to be installed.
The programmable physical dial scrolls through up to 40 shortcuts per
application with specific functions like zoom, brush size, layers,
etc. You can also quickly switch between key groups within an
application (like sketching, coloring, and editing) by keying the Quick
Keys’s “Set” button. The Quick Keys’s OLED display makes it easy to
remember which keys are assigned to which shortcut and the programmable
color ring indicates which function you’re currently using. The
adjustable sleep timer ensures your Quick Keys will remain on while you
work. The Quick Keys was designed for comfort which the wireless
connection allows by giving the artist freedom to position the
controller in four different orientations to best fit your preferences.
Left-handed
or right-handed, wireless or wired, with 5 sets of 8 keys, that allows
up to 40 programmable functions per application, the Quick Keys will
optimize your workflow.
What is not compatible and not supported with the Quick Keys and Xencelabs driver: Raspberry PI (all versions), Android operating systems, iOS (Apple iPad, iPhone) operating systems, Stream Deck, Sony PlayStation, Windows Xbox.
Specification
Color
Carbon Black
Product dimensions (W x H x D)
6.2 x 2.48 x 0.47 in / 157.6 x 62.5 x 12 mm
Product weight
142g / 0.31lbs
Display
Text and symbols can be read horizontal or vertical
Time before device sleeps from no activity
Set by user
Quick Application hours per charge
25-53 hours (1.5 hours charging time)
Quick Application Cable L included
USB-A to USB-C Right Angle 90º Wireless via USB/USB-C connection
Custom shortcut
8 programmable application, with 5 application sets, for up to 40 unique short-cut application
Dial
Up to 4 (user can define)
Security
Kensington NANO Lock
Connectivity
Wireless or USB
System requirements
Windows®7 or later, Mac OS X 10.12 or later, Windows ARM, Linux version coming soon, wireless or cable connection requires USB Type-A port (includes Type-C adapter)
Warranty
24 months
Certifications
CE/WEEE/FCC/KC/TELEC/EAC/RCM/RoHS/UKCA /WERCS/NOM/CA PROP65. Windows® is either a trademark of Microsoft Corporation in the United States and/or other countries. OS® X is a trademark of Apple Inc. registered in the U.S. and other countries. Kensington NANO Lock is a registered trademark of ACCO Brands. All other company names and product names are registered trademarks of their respective owners.
Doesn't supported with the Quick Keys driver
Raspberry PI (all versions)；Android operating systems； iOS (Apple iPad, iPhone) operating systems； Stream Deck； Sony PlayStation； Windows Xbox；
What’s in the Box
Xencelabs Quick Keys (K02-A)
Carrying Case (for Quick Keys and Cable)
Adapter / USB-A to USB-C
Dongle (ACD12-A)
USB-C cable L / USB-A to USB-C
Quick Start Guide / Thank You Card
Warranty Card * 1 PC
FAQ
How many applications can I set up for custom actions?
You can set up 29 applications that you can assign 4 Dial custom actions to, and 40 button customer actions for.
I have a display or pen tablet from another manufacturer, can I still use that Quick Keys?
Yes, but why not buy our tablet? When you install the Xencelabs Driver, it will ask you if you would like to install only the Quick Keys portion or the entire Driver that also supports our Pen Tablet. You would select Quick Keys only.
Can I connect the Quick Keys to the Bluetooth application on my computer?
No, we provide a Wireless Dongle to be used to make the Bluetooth connection. Since only Xencelabs products will use this, it will eliminate any lag that might be encountered with using the Bluetooth connection that comes with your computer.
Do I need to install a Driver to make the Quick Keys work?
Yes, Xencelabs provides a Driver for current or near current macOS, Windows, and Linux operating systems. The Driver must be installed for the Quick Keys to work.
I have settings for Adobe PS, and I want to share them with my friends, can I do this?
Yes, using the Settings program you can share all your custom settings or only the setting for one application.
