This bundle includes everything you need. At the center is the Xencelabs Pen Tablet, 3 Button and Thin Pen. At the top of the tablet are three nested buttons which give you quick access to tablet settings, pen settings and switch display. Together, quick settings access buttons and a minimalist ergonomic design ensure you’re comfortable through long creative days.
Also included in the bundle is the Xencelabs Quick Keys, which enables artists to incorporate shortcut keys into their regular workflow through an easy-to-use interface. The remote’s OLED display and physical dial allow you to create up to 40 shortcuts per application and group sets of related functions like sketching, coloring, and editing. Creatives who previously found shortcut keys cumbersome to use, can now benefit from a powerful efficiency booster. Our tools are powered by the driver built from the ground up with input from creatives like you. One of the new features allows users to retain their customized settings after an update.
The bundle ships with a protective carrying case for your tablet and all of your accessories including the Quick Keys, the pen case that contains both digital pens, dongle, adapter, nibs, and nib extractor, and a drawing glove.
- Specifications
- Overview
Model number
BPH1212W-K02-A
Color
Black
Warranty
24 months
Cable
2 x USB-C cable (L)
Certifications
CE/WEEE/FCC/CQC/KC/TELEC/EAC/RCM/RoHS/ UKCA/WERCS/NOM/California65/CB/SRRC/FAC/ NBTC/EMC/NCC/BSMI/SDPPI/NTC/IMDA/ SIRIM/SDPPI
System requirements
Windows 7 or later, Mac OS X 10.12 or later, Linux; wireless or cable connection requires USB Type-A port (includes Type-C adapter).
- Pen Tablet
Model number
BPH1212W-A
Dimensions (W x H x D)
12.61 x 9.16 x 0.3 in / 320.5 x 232.5 x 8 mm
Active area size
10.33 x 5.8 in / 262.4 x 147.4 mm
Active area aspect ratio
16:9
Weight
710.5 g / 1.57 lbs (approx.)
Hours per charge
16 hours (2.5 hours charging time)
Ports included
USB-C
Security slot
Kensington Nano Security Slot™
Connectivity
Wireless or USB
Technology
Battery-free EMR (Electro-Magnetic Resonance)
- Battery-free Pens
Pen models
PH25 (3 Button Pen) / PH6-A (Thin Pen)
Pen buttons
3 Button Pen: 3 buttons + eraser / Thin Pen: 2 buttons + eraser
Pressure levels
8192 levels (both pens)
Pen tilt range
60 degree (both pens)
Pen grip material
Soft touch rubber
Pen size
3 Button Pen: 157.56 x Φ14.73 mm / Thin Pen: 157.54 x Φ9.5 mm
Pen weight
3 Button Pen: 17 g / Thin Pen: 12 g
- Quick Keys
Model number
K02-A
Color
Black
Product dimensions (W x H x D)
6.2 x 2.46 x 0.47 in / 157.6 x 62.5 x 12 mm
Product weight
142 g
Display
3.12-inch OLED display; clearly displays key functions
Directions
4 directions (0° / 90° / 180° / 360°); text and symbols can be read horizontal or vertical on the OLED display
Sleep timer
30, 60, 90, 120 minutes, never (set by user)
Hours per charge
25-53 hours (1.5 hours charging time)
Custom buttons
8 per set. There can be 5 sets giving a total of 40 short-cut keys
Dial
Up to 4 modes (user can define)
Security slot
Kensington Nano Security Slot™
Connectivity
Wireless or USB
